PR02PT100RTDPrecisionTemperatureprobe
Overview
4 wire PT100 sensor housed inside stainless steel potted shaft with 3M of PTFE cable
Customise this datalogger
Part of a suite of products designed to work as a complete monitoring system
- Length
RTD Liquid probe
Available in 50mm and 100mm length
Cable
3m of Flat pair PTFE cable
Compatible
With 4 wire PT100 data loggers
Information
Product Description
4 wire PT100 sensor housed inside stainless steel potted shaft with 3M of PTFE cable. Recommended for use between -80 ~ +250°C, available in two different shaft lengths.
Ideally suited to applications requiring the collection of precise temperature data.
- 50mm shaft length
- 100mm shaft length
Specifications
- Manufacturer
LS
- Sensor type
Class A | 4 wire RTD/PT100
- Range
-80 ~ +250°C
- Accuracy
-80°C = 0.31°C
0°C = 0.15°C
100°C = 0.35°C
200°C = 0.55°C- Material
PTFE Cable
- Dimensions
4mm diameter
[PR02- 50] 50mm version
[PR02- 100] 100mm version- Environment
Air/Liquid
- Operating Conditions
-80 ~ +250°C
- Features
Precise and accurate
