RFPulse2000AUSBandWirelessPulseDataLogger
By MadgeTech Data LoggersOverview
Pulse counting, USB or wireless radio data logger.
Customise this datalogger
Part of a suite of products designed to work as a complete monitoring system
- Power adapter
- Wireless Transceiver
- Software upgrade
Wireless Pulse Counter
Unique solution for recording pulse output signals from a variety of sensors, calculating pulse count and pulse rate.
Cloud
Compatible with MadgeTech cloud for remote data collection via the internet
LCD Display
The display allows immediate viewing of current readings along with historical statistics and alarm status
Information
Product Description
The RFPulse2000A is a compact data logger for monitoring, counting and recording data delivered by pulse outputs.
it is either battery or mains powered so it can be deployed as a handheld, situated on a desk or mounted to a wall using the innovative supplied bracket. View real-time data on the LCD screen, trigger local audible/visual alarms and connect to a USB computer for periodic analysis. If at a later date you want to link the data loggers up to deliver real-time alarms and data then we need to check signals and recommend the required number of RFC1000 repeaters.
Ideally suited for applications where kwH and water usage data needs to be collected, centrally stored on a network and accessible on-line using cloud based technology.
Hardware Features
- Direct pulse connection via terminal block.
- USB and Wireless connectivity .
- Pulse data logger
- Email and audible alarms.
- LCD display.
- Battery or optional mains powered.
- Cloud services compatibility.
Applications
- Energy meter monitoring.
- Flow rate monitoring.
- Pulse counting.
MT4 standard software Features
- Engineering Units – Scale your pulse data against engineered parameters like litres per minute
- Graph – Multi plot, multi parameter with zoom functions linked to statistics
- Tabular – Time versus parameter data presented in a printable table
- Reports – Powerful module which collates data collected from multiple devices
- Workflows – Automate routine tasks such as download, configuration, reporting and saving collected data
- Time markers and value lines – Assist in organising data into stages and clearly presenting pass/fail limits
- Advanced statistics – Sterilisation, MKT, time until threshold, mathematical channels and more..
- .CSV export – Single button export results in generation of a fully formatted spreadsheet.
- Annotation – Apply cooling flags and markers on your results
- Configuration – user definable with multiple data logging batch programming facility
- Secure archive – Automatically save critical data within a secure database
Supplied with: Sensor connector, battery, mounting/stand bracket , MT4 software and USB cable.
Optional:
- MadgeTech Secure SVP for FDA 21 CFR Part 11 Compliance supported with GxP IQ/OQ/PQ validation documentation
- MadgeTech Relay and Cloud services for real-time and alarm management on any internet enabled device.
- Mains power adapter
Specifications
- Manufacturer
Madgetech
- Parameter(s)
Pulse
- Usage Type
Multi use
- Connectivity
USB and wireless radio
- Sensor internal or external
Internal
- Channels
1 channel
- Memory
16,128 readings
- Sample rate
1 reading every second ~ 1 reading every 24 hours
- Range
Input Low 1.070 V
- Material
ABS Plastic
- Power
Battery 9v Lithium or mains power adaptor
- Battery Life
5 years typical at a 10 minute reading rate
- Dimensions
88.9 mm x 76.2 mm x 24.1 mm
- Environment
-20 °C to ~ 60 °C, 0 %RH to 95 %RH non-condensing
- Alarm
Audible Alarm (built in), emails
- Features
USB and Wireless , email & audible alarms, , LCD display, battery or mains powered
