RHTemp1000EX Temperature and Humidity Data Logger

£505.00

Stainless steel, multi use, battery operated temperature and humidity data logger. Cost effective, for use in harsh environments, ATEX certified with ISO17025 calibration.



Sub-total
£505.00
QuantityPriceYou Save
100+£439.3513%
50+£449.4511%
25+£469.657%
10+£479.755%
1+£5050%

Product Description

The RHTemp1000EX is an ATEX certified, stainless steel temperature and humidity data logger suitable for accurately collecting and storing time stamped data.

The battery powered, self-contained data logger can be configured using a computer with a USB port running Windows 10, deployed and left in-situ within zone 0~2 environments for up to 2 years (hourly recording interval) before reconnecting to a computer for data extraction and analysis.

Scope of use

Electrical Protection Concepts: ISO/IEC: 60079-11 Ex ia – Ex ic, Intrinsic Safety Zones 0-2.
Equipment Protection Level: Ga – Gc, Zones 0-2.
Gas Groups: IIA – IIC.
Temperature Class: T4.

This cost effective solution utilises the free powerful MadgeTech software for simple or in-depth analysis.  Programming and downloading multiple data loggers is quick and easy using the simple batch program function and up to 18 loggers at a time using 3 x IFC406 interfaces.  Multiple loggers can be overlaid, viewed, annotated and exported together with lethality auto calculated in the software.

  • Includes ISO17025 calibration certificate.
  • Optional secure software is available for applications that require 21 CFR 11 compliance.

Features

  • Compact
  • Stainless steel
  • ATEX Certified
  • 21 CFR 11 secure validated software (optional)
  • Cost effective

Applications

  • Medical and Pharmaceutical
  • EtO ethylene oxide
  • Hazardous and Hostile Environment Monitoring
  • Validation exercises
Manufacturer

Madgetech

Parameter(s)

Temperature and humidity

Usage Type

Multi use

Connectivity

USB via IFC400 or IFC406 interface

Sensor internal or external

Internal

Channels

Two

Sensor type

Resistance Temperature Detector (RTD)
Humidity Capacitive Polymer

Memory

16,350 readings per channel

Sample rate

1 reading every second up to 1 reading every 24 hours

Range

-40 °C ~ +80 °C
0 %RH ~ 100 %RH (non-condensing)

Accuracy

+/- 0.5°C
±3 %RH maximum (0 °C ~ 55 °C)

Resolution

0.1°C
0.1 %RH

Material

316 Stainless Steel

Power

Battery 3.6v lithium

Battery Life

730 days typical @ 25°C, 15 minute recording interval

Dimensions

42 mm x 24.6 mm x 24.6 mm

Operating Conditions

-40 °C ~ +80 °C , 0 %RH ~ 100 %RH

Certification

ATEX
Electrical Protection Concepts: ISO/IEC: 60079-11 Ex ia – Ex ic, Intrinsic Safety Zones 0-2
Equipment Protection Level: Ga – Gc, Zones 0-2
Gas Groups: IIA – IIC
Temperature Class: T4

Instruction Manual
RHTemp1000ex Product User Guide WPLSPDF533 KB
RHTemp1000EX Standard CertificatePDF700 KB
Software
MadgeTech SoftwareZIP18MB
