TR72A-S
Wi-Fi, Bluetooth and USB Precision Humidity and Temperature Data Logger
Part of Wessex Power • Looking for Compliant Monitoring Solutions? Visit wessexpower.co.uk
Call 01929 459459 or email with any questions
Bluetooth humidity and temperature data logger
Part of a suite of products designed to work as a complete monitoring system
Measurement Range
IP64. Temperature 0 to 55 °C, humidity 10 to 95% via supplied sensors
PDF Reporting
Configure, analyse, PDF reporting using Bluetooth on iOS
Cloud access
Upload recorded data to the free WebStorage Service (WSS)
Standalone, robust (IP64) humidity and temperature data logger utilising mobile phone and Bluetooth technology to setup, record, extract and present your collected data using one or more of the three free issued mobile applications (iOS and Android)
(1) T&D Thermo application - used to apply a profile to your data logger(s)
If using T&D Thermo to extract collected data it can be paired with a free (2) WebStorageService (WSS) account, this function centralises your data online which in turn can be accessed by authorised users via the internet.
Please note: The data is not uploaded to WSS in real-time. The data is available after the user has manually downloaded and sent the data to WSS.
Alternatively you can generate a PDF file using (3) TR4 report, this can be printed and shared from within the mobile phone application.
Using these applications we can tailor a solution to meet the needs of an individual an organisation or to provide evidence to an end user.
This battery powered data logger displays, collects and stores humidity and temperature data measured by an integrated sensor supplied in the box.
Boasts an LCD display that rotates between temperature and humidity readings, along with recording and battery status.
Mobile applications
TandD
Humidity
Temperature
Multiple use
Bluetooth
External
2
Thermistor
Polymer Resistance
8'000 readings
1 reading a second ~ 1 reading an hour
0°C ~ 55°C
10% ~ 95%
+/- 0.5°C
+/- 5% rH
0.1°C
1% rH
ABS plastic
Internal battery
18 months estimated battery life when recording data at an interval of more than 10 seconds and displaying a graph in the app once a day.
H 62 mm x W 47 mm x D 19 mm (excluding protrusions and sensor)
-10°C ~ +60°C
<90% rH
Globally accessible historic data
Free software
LCD display
