ULT90UltraLowTemperatureDataLoggingSystem
By MadgeTech Data LoggersOverview
Over 1 year battery life, -86°C, 21 CFR 11 compliant
Includes calibration certificate
Customise this datalogger
Part of a suite of products designed to work as a complete monitoring system
- ULT90 9 or 15 data logger system
- Interface - Required to download data
Rated for -86 °C
Up to 32000 temperature readings over -86 °C to +35 °C measurement range
ISO17025 Calibration
Tested at -80 and +25 °C and supplied with certificate
Validated
21 CFR Part 11 compliance and GxP documentation included
Information
Product Description
The ULT90 Ultra low temperature probeless data logging system is supplied with all that is required to validate appliances and processes operating at -86°C ~ +30°C in compliance with pharmaceutical regulated standards.
Supplied data loggers have integral sensors which are simple to install, rather than wrestling with wires and probe tips that can be disturbed during regular operation, our data loggers are simply placed inside your freezer or dry ice shippers. When partnered with the powerful and easy to use MT4 software, you can rapidly synchronize the data loggers to record and store temperature and time data. Once your validation exercise has been concluded, graphical, tabular and statistical reports can be generated.
System comprises of;
- Probe less multiple use data loggers rated to -86°C
- Calibration certificate
- Computer interface
- 21 CFR Part 11 compliant software
- Carry case
- IQ/OQ/PQ GMP Validation documentation
Options: Available with 9 or 15 data loggers
Features
- -86°C ~ +30°C validation
- Standalone and battery powered
- Battery life 1 year (typical)
- 21 CFR 11 secure validated software included
- Calibration certificate included
Applications
- Validation of dry ice shippers and shipments
- Validation of ULT Ultra Low Temperature freezers
- Routine monitoring of products stored at -80°C
MT4 standard software Features
- Graph – Multi plot, multi parameter with zoom functions linked to statistics
- Tabular – Time versus parameter data presented in a printable table
- Reports – Powerful module which collates data collected from multiple devices
- Workflows – Automate routine tasks such as download, configuration, reporting and saving collected data
- Time markers and value lines – Assist in organising data into stages and clearly presenting pass/fail limits
- Advanced statistics – MKT, time until threshold, mathematical channels and more..
- .CSV export – Single button export results in generation of a fully formatted spreadsheet.
- Annotation – Apply cooling flags and markers on your results
- Configuration – user definable with multiple data logging batch programming facility
- Secure archive – Automatically save critical data within a secure database
Specifications
- Manufacturer
Madgetech
- Parameter(s)
Temperature
- Usage Type
Multi use
- Connectivity
USB via IFC300
- Sensor internal or external
Internal
- Channels
9 or 15 data loggers
- Sensor type
Thermistor
- Memory
32,767 readings per data logger
- Sample rate
1 reading every 5 seconds up to 1 reading every 30 minutes
- Range
-86 °C to +35 °C
- Accuracy
±1.0 °C
- Resolution
0.1 °C
- Material
ABS Plastic
- Power
Battery
- Battery Life
2 years typical at 25 °C, 1 min. reading intervals
1 year typical at -80 °C, 1 min. reading intervals- Dimensions
-86 °C to +35 °C (-122.8 °F to +95 °F), 0 %RH to 100 %RH
- Operating Conditions
-86 °C to +35 °C (-122.8 °F to +95 °F), 0 %RH to 100 %RH
- Features
over 1 year battery life, -86°C, 21 CFR 11, calibration certificates
Frequently Asked Questions
Yes, the data loger can be placed inside ultra low temperature freezers and dry ice shipping containers.
The solution is supplied with validation protocols, complete these to validate the 21 CFR Part 11 software and IOPQ the data loggers.
Certificates are ISO17025
Yes, the software will generate a value that can be used to calibrate the set point on the appliance. Reach out to talk to us about calibration method statements and guidance.
Downloads
Product Brochure
ULT90 Datasheet WPLSPDF • 1 MB
Software - Windows PC only
MadgeTech SoftwareZIP • 25MB
