iTag4-T

iTag4 Temperature Data Logger

£19.00 £19.00/unit

The TempSen iTag4 is a single use temperature data logger with detailed electronic time temperature indicator functionality. This temperature indicator by Tempsen is suitable for monitoring temperature data in transit for up to 90 days. Use this USB data logger to meet safety legislation and government compliance in your facility.

Sub-total
£19.00

Product Description

The TempSen iTag4 is a single use temperature, USB and PDF data logger, delivering all the functionality of a calibrated data logger but with the addition of a clear and detailed LCD display. Through this useful LCD display, the iTag4 data logger instantly provides users with details on recorded data, alarm excursions and transport duration statistics.

This disposable temperature data logger is designed to meet regulatory demands imposed on organisations operating in the field of pharmaceutical, biological and clinical trial supply chain. TempSen’s iTag4 data logger is ideally suited to both validation and verification exercises, where temperature must be maintained during transportation of time temperature sensitive materials.

Each iTag4 USB data logger is supplied, calibrated and ready to be configured using TempCentre, which can be installed on a Windows PC or any device with a web browser and USB port. Shipping profiles can be configured to last 1-90 days with user definable recording intervals and alarm ranges. After the data logging process, the LCD will deliver the critical information to the user. By connecting this PDF data logger to a computer, users can gain access to a detailed and easily downloadable report.

Main features:

  • 21 CFR Part 11 Compliant
  • Suitable for frozen, refrigerated and ambient monitoring in transport
  • End user readable with direct USB connection
  • PDF automated reporting
  • Supplied with calibration certificate
  • Complete software free operation – Internet configuration utility
  • Software installation – Using free TempCentre software (See Downloads section)

Contact us today to find out more about the iTag4 temperature data logger. Simply call 01929 459459 today and receive our expert, friendly service. Alternatively, send an email to sales@loggershop.co.uk.

Usage Type

Single Use

Memory Capacity

14400 readings

Measurement Range

-30°C...70°C (-22°F...158°F)

Accuracy

±0.3°C

Resolution

0.1°C / °F

Logging Interval

1 minute...2 hours

Alarm Ranges

High and low alarms

Battery

3.0V CR2032 lithium battery

Battery Life

90 days

Shelf Life

2 years (1 year if activated)

Display

LCD
•OK(√), Alarm(x), Running status
•Triggered alarm zone
•Duration time of each alarm zone
•Temperature statistics (max, min, avg)

Connection

USB

Automatic Data File

Encrypted PDF report with embedded raw data

Software

TempCentre Data Management Software

Compatibility

Windows PC

Dimensions

93mm L x 45mm W x 7mm H

Weight

Approx. 22g

Calibration

Factory Sampling 6-point Calibration (AQL 0.25)

Approval

CE, WHO PQS Code E006/044, EN12830, RTCA-DO160G, IATA PI970 II, WEEE, RoHS, Manufacturer's Validation Certificate

Product Brochure
TempSen_ITAG4_3.X_Data_Sheet_WPLSPDF604 KB
TempSen_Cold_Chain_Data_Loggers_Catalogue_WPLSPDF1.4MB
Instruction Manual
TempSen_ITAG4_3.X_Quick_Guide_WPLSPDF525 KB
Lithium_Battery_IATA_59TH_Compliance_Statement_2018PDF103 KB
Software
TempCentre SoftwareEXE30MB

Product Description

The TempSen iTag4 is a single use temperature, USB and PDF data logger, delivering all the functionality of a calibrated data logger but with the addition of a clear and detailed LCD display. Through this useful LCD display, the iTag4 data logger instantly provides users with details on recorded data, alarm excursions and transport duration statistics.

This disposable temperature data logger is designed to meet regulatory demands imposed on organisations operating in the field of pharmaceutical, biological and clinical trial supply chain. TempSen’s iTag4 data logger is ideally suited to both validation and verification exercises, where temperature must be maintained during transportation of time temperature sensitive materials.

Each iTag4 USB data logger is supplied, calibrated and ready to be configured using TempCentre, which can be installed on a Windows PC or any device with a web browser and USB port. Shipping profiles can be configured to last 1-90 days with user definable recording intervals and alarm ranges. After the data logging process, the LCD will deliver the critical information to the user. By connecting this PDF data logger to a computer, users can gain access to a detailed and easily downloadable report.

Main features:

  • 21 CFR Part 11 Compliant
  • Suitable for frozen, refrigerated and ambient monitoring in transport
  • End user readable with direct USB connection
  • PDF automated reporting
  • Supplied with calibration certificate
  • Complete software free operation – Internet configuration utility
  • Software installation – Using free TempCentre software (See Downloads section)

Contact us today to find out more about the iTag4 temperature data logger. Simply call 01929 459459 today and receive our expert, friendly service. Alternatively, send an email to sales@loggershop.co.uk.

Usage Type

Single Use

Memory Capacity

14400 readings

Measurement Range

-30°C...70°C (-22°F...158°F)

Accuracy

±0.3°C

Resolution

0.1°C / °F

Logging Interval

1 minute...2 hours

Alarm Ranges

High and low alarms

Battery

3.0V CR2032 lithium battery

Battery Life

90 days

Shelf Life

2 years (1 year if activated)

Display

LCD
•OK(√), Alarm(x), Running status
•Triggered alarm zone
•Duration time of each alarm zone
•Temperature statistics (max, min, avg)

Connection

USB

Automatic Data File

Encrypted PDF report with embedded raw data

Software

TempCentre Data Management Software

Compatibility

Windows PC

Dimensions

93mm L x 45mm W x 7mm H

Weight

Approx. 22g

Calibration

Factory Sampling 6-point Calibration (AQL 0.25)

Approval

CE, WHO PQS Code E006/044, EN12830, RTCA-DO160G, IATA PI970 II, WEEE, RoHS, Manufacturer's Validation Certificate

Product Brochure
TempSen_ITAG4_3.X_Data_Sheet_WPLSPDF604 KB
TempSen_Cold_Chain_Data_Loggers_Catalogue_WPLSPDF1.4MB
Instruction Manual
TempSen_ITAG4_3.X_Quick_Guide_WPLSPDF525 KB
Lithium_Battery_IATA_59TH_Compliance_Statement_2018PDF103 KB
Software
TempCentre SoftwareEXE30MB
