TC101ATemperatureDataLogger

Name: TC101A Temperature Data Logger
Brand: MadgeTech Data Loggers
SKU: TC101A
Price: 158.94 GBP
Availability: InStock

By MadgeTech Data Loggers

From: £158.94

Overview

Thermocouple temperature logger for connection to any thermocouple probe.

Customise this datalogger

Part of a suite of products designed to work as a complete monitoring system

Probe Options
Calibration Certificate
Data Cable - Required to download data
Protective Enclosure
Spare Battery

* Calibration takes between 3 - 7 business days Add and customise

Measures

Temperature within the range of -270 to +1370 °C. Compatible with thermocouples probes.

Long runtime

Collect up to 1MB of data for up to 10 years

Cost Effective

Utilises the free powerful Madgetech software for simple or in-depth analysis. Optional secure software is available for applications that require 21 CFR 11 compliance.

Information

Product Description

Please note: Requires External Probe, IFC200 interface and free software (see downloads section).

The TC101A external probe data logger can be used with eight different type of thermocouple probes making it the ideal choice for a wide range of applications. This enables a wide range of recording temperatures from -270°C all the way up to 1820°C, depending on the type of thermocouple probe used.

Factoring in the large memory capacity of 500,000 readings and a battery life of up to 10 years, the TC101A is a truly multifunctional data logger.

Using the free Madgetech 4 software, users are able to export data to excel and PDF formats and perform detailed analysis and produce custom reports.

Specifications

Manufacturer: Madgetech
Parameter(s): Temperature
Usage Type: Multi use
Connectivity: USB via IFC200
Sensor internal or external: External probe
Channels: Single
Sensor type: External thermocouple
Memory: 1,047,552 readings; software configurable memory wrap
523,776 readings in multiple start/stop mode or trigger settings mode
Sample rate: 1 reading every second up to 1 reading every 24 hours
Range: -40 °C to +80 °C
Accuracy: +0.5°C
Resolution: 0.01°C
Material: Polycarbonate
Power: Battery
Battery Life: 10 years typical at a 15 minute reading rate
Dimensions: 35mm x 54mm x 15mm
Environment: IP54 for dry environments used with Waterbox101A for IP65 applications
Operating Conditions: -40 °C ~ +80°C and 0%RH to 95%RH non-condensing
Alarm: LED and in report
Features: External thermocouple, user replaceable battery, push button start, optional password protection, LED, 21 CFR 11, battery life indicator, up to 10 year battery life
