By LogTag Data Loggers


TIC20 40 day electronic temperature indicator with optional statistical electronic record keeping function.

Pass/Fail LCD

Indicates the status and value of monitored data against alarm threshold

Quad alarms

2 upper and 2 lower alarm thresholds

40 day operation

With statistical data retrieval via optional interface.


Product Description

Factory and user configurable, the TIC20 is both a low cost alternative to a single use data logger and a more robust alternative to traditional sticker/indicator. Critical data is recorded and can be extracted with the air of an optional interface cradle, enabling users to keep an electronic record of supply chain issues. Aside from lower costs and audit compliance the TIC20 also enables users to deploy a simple supply chain monitoring solution that requires minimal training due to the intuitive, large clear display and keypad.

  • At-a-glance summary with ‘OK’/’Reject’ alarm status.
  • 4 freely configurable upper/lower temperature alarms.
  • Review statistical data on device for up to 20 days prior.
  • Download of statistical data via optional interface.

The LogTag® TIC20 is a versatile, wide range, multi-trip Temperature Indicator, featuring high resolution temperature readings over a measurement range of -40°C to +85°C (-40°F to +185°F). Enclosed in a robust and durable polycarbonate case, the TIC20 features a real time clock, which provides date/time stamps for each temperature reading.

Using the LogTag® Interface and the freely available companion software LogTag Analyzer, the LogTag® is easily set-up for recording conditions including delayed start, sampling interval, number of readings, continuous or fixed number of readings and configuration of conditions to activate the ALERT indicator. Readings are downloaded using LogTag® Analyzer, which provides facilities for charting, zooming, listing data statistics and allows exporting the data to other applications such as Excel.

The LogTag® TIC20 complies with the relevant international standards for temperature monitoring devices, such as FCC, CE, C-TICK, and RoHS. This not only demonstrates the quality of the LogTag® TIC20, but underlines its suitability for temperature monitoring applications where accuracy and consistency is required.

Please contact us on 01929 459459 to discuss volume and annual contract discounts.


Measuring Range



+/- 0.5°C [-10 to +40 °C]




40x Min/Max days
6 minute recording interval
1st activation of each alarm including duration


Alarms and temperature data on display


21 CFR Part 11
