TREL-8Datalogger

Name: TREL-8 Data logger
Brand: LogTag Data Loggers
SKU: TREL-8
Price: 42.59 GBP
Availability: InStock

By LogTag Data Loggers

From: £48.58

Overview

The TREL-8 data logger is ideal for ultra-low temperatures with a temperature sensor and is user configurable for ULT freezers and dry ice temperature monitoring, with 8000 readings and clear LED alarm.

Customise this datalogger

Enhance your monitoring with these options

Probe
Calibration Certificate *
Cradle - Required to download data
Bracket

* Calibration takes between 3 - 7 business days Add and customise

Records -90 °C

Up to 8000 temperature readings over a range of -90 to +40 °C from interchangeable remote probe

Visual Alarm

Green and red lights indicate if collected data is in or out of the user defined (acceptable) limits

Software

Take advantage of LogTag's freely available companion software LogTag© Analyser

Information

Product Description

The TREL-8 data logger is a temperature data logger, ideal for recording ultra-low temperatures via an external temperature sensor. Designed for the routine monitoring and validation of ultra-low temperature freezers at -80°C.

Data logger instructions

Simply configure and reconfigure the TREL-8 temperature data logger using the USB interface cradle and free issued LogTag data logger software, deploy the temperature sensor into the freezer and mount the data logger on top or on the side of the freezer.

Periodic visual inspection of the data logger will present the user with a green or red flashing LED indicating if recorded temperatures are in or out acceptable thresholds. A full audit can be performed by extracting and distributing collected data to assigned personnel. Rapid configuration, retrieval of collected data and analysis is performed using the free issued LogTag data logger software in conjunction with a USB interface cradle.

Note: A temperature data logger probe must be purchased and configuration/ data retrieval requires a USB interface cradle.

Specifications

Manufacturer: LogTag
Parameter(s): Temperature
Usage Type: Multiple
Connectivity: USB via interface
Sensor internal or external: External
Channels: 1
Sensor type: Thermistor
Memory: 8031
Sample rate: 1 minute ~ 18 hours
Range: -90°C ~ +40°C
Accuracy: +/- 1.7°C
Contact our calibration department for advice on offset adjustment.
Resolution: 0.1°C between -90°C ~ -45°C
Material: Polycarbonate
Power: 3.6v low temperature battery
Battery Life: 900 days
Dimensions: 86mm x 54.5mm x 8.6mm
Environment: IP61
Operating Conditions: -20°C ~ +40°C
Suitable for use in dry ice shipment and ultra low temperature freezers
Alarm: Flashing LED and in report
Features: LED with confidence and alarm flashing function
Push button start
21 CFR Part 11 compliance
Computer Requirements: Windows PC
