UTRED30-16RDataLogger

By LogTag Data Loggers
From: £104.48

Overview

The uTRED30-16R temperature USB data logger features 166 day recording at 15-minute intervals all powered by 2 AAA batteries or a power supply. With a large display, LED and audible alerts.

Customise this datalogger

Part of a suite of products designed to work as a complete monitoring system

  • Select Probe
  • Calibration certificate
  • Bracket
* Calibration takes between 3 - 7 business days Add and customise

LCD Display

The display allows immediate viewing of current and min/max /alarm, daily entries over a 30 day period

Audible Alarm

Integrated audible alarm triggered if readings outside pre-set limits are breached

Replaceable Battery

2 x AAA can be sourced and replaced without special tools.

Information

Product Description

The LogTag uTRED30-16R is a temperature data logger with USB functionality for downloadable data and easy reporting. This model represents a significant update and enhancement on the current TRED30-16R, with improved features based on customer feedback. Measure temperature with ease and view 30 days’ worth of min/max data and alarm occurrences on the large, easy to read display.

LogTag uTRED30-16R Temperature USB Data Logger Features:

  • New large easy-to-read display
  • Read current temperature and latest min-max temperature at a glance
  • User can check and re-set min-max temperature reading at any time
  • Flashing red LED and audible alarm signals a temperature alarm
  • Read alarm status for up to 30 days at a glance
  • Powered via a standard plug-in power adaptor and a USB cable
  • Powered by 2 x AAA Alkaline batteries (user replaceable) if external power is not available
  • Second battery back-up via a coin cell to ensure no data is lost even if the power source and Alkaline batteries fail.
  • Download data via LogTag Analyzer data logger software or directly to a PDF report - no software or interface device is required.

Specifications

Manufacturer

LogTag

Parameter

Temperature

Usage Type

Multiple Use

Connectivity

Integrated USB interface

Sensor internal or external

External

Channels

1

Sensor type

Thermistor

Internal Storage Memory

16,129 (112 days at 10 minute recording interval)

LCD Display

30 days of Min/Max/Duration and alarm statistics

Sample rate

30 seconds to 18 hours

Measuring Range

-40°C ~ +99°C

Accuracy

< +/-0.5°C between -20°C and +40°C Contact our calibration department for advice on offset adjustment.

Resolution

0.1°C

Material

Polycarbonate

Power

AAA batteries x 2
Mains power via USB adaptor

Battery Life

Up to 12 months on battery power.

Dimensions

123mm (H) x 63mm (W) x 12.5mm (D)

Environment rating

IP51

Operating Conditions

-30°C ~ +60°C

Alarm

LED, LCD, Audible.
In report details

Features

Audible and visual alarm (on screen and LED)
Auto pause logging when probe disconnected.
USB PDF reporting

Computer Requirements

Windows PC
