TC101A
Eco-friendly Thermocouple Data Logger
Part of Wessex Power • Looking for Compliant Monitoring Solutions? Visit wessexpower.co.uk
Call 01929 459459 or email with any questions
Temperature data logger with integral sensor
Part of a suite of products designed to work as a complete monitoring system
Measures
Internal RTD temperature sensor collects from -40 to +80 °C with a resolution of 0.01 °C
Large memory
Collect up to 2M data points and download via direct USB connection
Eco friendly
Serviceable device with up to 10 years battery life when recording at 15 minute interval.]
Please note: Requires IFC200 interface and free software (see downloads section).
The Temp101A is a compact, flexible and cost effective temperature data logger. Featuring an impressive 2,000,000 memory points and up to 10 year battery life, the Temp101A is ideally suited to long term validation studies or where a large amount of data needs to be collected.
The device can be started up to 18 months after programming or by "push button start" by the operator in the field to pre-programmed settings. High and Low alarms can be programmed by the user and alerted in the field by flashing LED's or can be added to the report in the software after the event.
The battery is field replaceable and a battery life indicator in the software alerts users of remaining usage. Used with the IFC200, the Temp101A allows for very fast data download and clever batch start allows for rapid programming on multiple devices.
21 CFR 11 compliant when used with the optional Madgetech secure software.
Applications suited, but not limited, to the Temp101A are: Clinical trials; HVAC; museums; places of worship; temperature mapping and monitoring of appliances.
Supplied with mounting bracket.
Madgetech
Temperature
Multi use
USB via IFC200 interface (sold separately)
Internal
Single Channel
Internal Precision RTD Element
2,095,104 readings; software configurable memory wrap
698,368 readings in multiple start/stop mode
1 reading every second up to 1 reading every 24 hours
-40 ~ +80°C
+0.5°C
0.01°C
Polycarbonate
Battery
10 years typical at a 15 minute reading rate
35mm x 54mm x 15mm
IP54 for dry environments used with Waterbox101A for IP65 applications
-40 °C ~ +80 °C and 0 %RH to 95 %RH non-condensing
LED and in report
User replaceable battery, push button start, optional password protection, LED, 21 CFR 11, battery life indicator, up to 10 year battery life
