uSric-4Datalogger

By LogTag Data Loggers
From: £15.18

Overview

The uSric-4 data logger is a user configurable, single use temperature data logger with 4000 measurement points, direct USB connection.









Customise this datalogger

Part of a suite of products designed to work as a complete monitoring system

  • Calibration Certificate
  • Pre configuration
  • Protective Enclosure
  • Bracket
* Calibration takes between 3 - 7 business days Add and customise

USB Direct

Generate PDF report using free utility or download data with LogTag© Analyser

Single Use

<180 day duration transport data logger -30 to + 60 °C

User Configurable

Apply profile using PC software before use

Information

Product Description

The uSric-4 is a user configurable, single use temperature data logger with direct USB connectivity. It is ideally suited to supply chain monitoring and validation exercises where the recipient of the shipment needs to review collected data without requiring a bespoke interface.

A simple solution for shipments

Anybody shipping time temperature sensitive products will need to verify acceptable environmental conditions were maintained throughout the journey, the user configurable uSric-4 data logger delivers a simple, high quality and cost effective solution.

LogTag data logger software is required to configure and download the data logger and can be used to perform analysis i.e. plotting saved data in graphical, tabular, statistical formats and cross referencing multiple plots on one time line.

Supplied with USB cap, instructions, 2nd label for shipping labels and LogTag Analyzer data logger software.

Specifications

Manufacturer

LogTag

Parameter(s)

Temperature

Usage Type

Single

Connectivity

Direct USB

Sensor internal or external

Internal

Channels

1

Sensor type

Digital

Memory

4000

Sample rate

1 minute ~ 6 hours

Range

-30°C ~ +60°C

Accuracy

< +/- 0.5°C between -5 and +30°C

Resolution

0.1°C between -15°C and + 55°C

Material

Polycarbonate

Power

Battery

Battery Life

4320 hours in operation
17520 hours on the shelf

Dimensions

93mm x 54.5mm x 8.6mm

Environment

IEC 60529, IP64 with USB cap fitted

Operating Conditions

-25°C ~ +60°C

Alarm

LED and in post analysis report

Features

Direct USB connection
Detailed analysis and automated data distribution
User configurable
21 CFR Part 11 and Annex 11 compliant

Computer Requirements

Windows PC

Compliance

RTCA/DO‐160G section 21 as category H
